Description
GP-98N: The Comet triple band series were the first and are still one of the best in the market using Comet’s SLC system. The SLC system is an advanced mechanism developed originally by Comet in order to greatly improve the gain on Dual and Triple band antennas. Through the implementation of the Air-Core Type Shaping Element Phase System and the Phosphor Bronze Element the loss during the existing Phase Shift Peak has been substantially reduced.
With the highest power rating in their class, these base station antennas are ready to handle long QSOs from your high-power VHF/UHF radios. Completely factory tuned and no adjustment is necessary. The fiberglass construction assures long durability and is fully water resistance.
Specifications:
Frequency range: 144/430 /1200MHz (Wide reception range: 100 ~ 170/350 ~ 470/840 ~ 1400MHz)
Configuration: 2x 5/8λ (144MHz) – 5x 5/8λ (430 MHz) – 12x 5/8λ (1200 MHz)
Max power: 300W SSB (144/430 MHz) – 200W SSB (1200 MHz)
Gain: 6.5 / 9 / 13.5 dBi
Max resistance to wind speed: 40 m/sec.
Connector: N (NJ)
Length: 2.94 m
Radial length: 49 cm
Support pole diameter: 30 – 62mm
Weight: 1.5 kg
D-STAR COMPATIBLE
