Diamond V-2000 Tri Band 6/2/70cm Base Vertical Antenna.




V-2000: The V2000 utilizes a linear phase shift design to couple the different frequency band sections together. A watertight joint assembly connects the two antenna sections into one rigid assembly. The resulting antenna has the same strength as a one piece structure.
This is the ideal antenna for FM operation on 6 meter, 2 meter, and 70cm bands. Similar in construction to the X200 dualband, the V2000 has an additional counterpoise radial adjustable for 6m (50-54 MHz only). With 6m activity, enjoy the freedom of 3 bands in one compact antenna.

Features / Specifications:
Fiberglass radome
Overlapping outer shells for added strength
Strong waterproof joint couplings
Stainless steel hardware
Wideband performance
Highest gain
High wind rating
DC ground; antenna element and radials connected to mounting pipe
Three radials
Frequency: 6m/2m/70cm
Gain: 2.15dBi (50~52MHz), 6.2dB (144MHz), 8.4dB (430MHz)
Power rated: 150W
Connector: SO-239
Type: 1/2, 2 X 5/8, 4 X 5/8
Length: 2.5m
Radial length: 92cm
Mast size: 30-62mm
Wind velocity: 50m/sec
Weight: 1.2kg
