Yaesu G-800DXA Medium Heavy Duty Antenna Rotator





G-800DXA: Is a medium duty antenna rotator with automatic brake release, 450 ° rotation, overlap indicator, preset control, variable speed control, slow start / stop, etc. The illuminated control box has a 360 degree reading, with a moving beam direction gauge. Comes with a weather resistant motor connector and a quick connect control plug for a fast and trouble free connection.
Yaesu medium duty rotators systems, G-800DXA, are designed to rotate large professional and professional tower mounted radio antennas under remote control from the operating position of the station.
The factory-lubricated rotary unit is housed in die-cast aluminum and coated with melamine resin, to ensure maintenance-free operation under all weather conditions. A mast alignment gauge on the rotator housing simplifies precise mechanical alignment during installation. Yaesu rotators have a fine reputation within the Amateur Radio community. When installing a new tower, or replacing an old rotator.
Suitable for HF/VHF and UHF antennas.

Power Supply Current Consumption: 0.5 A (220 VAC)
Power Supply Voltage: 220 VAC, 50/60 Hz
Rotor Voltage: 11 ~ 24 VDC
360° Rotation Time (Non Loaded): 100 ± 10 sec to 40 ± 5 sec (Variable)
Wind Load: 2 m^2
K-Factor: 180
Rotation Torque: 600 to 1,100 kgf-cm (43 to 80 ft-lbs)
Max. Vert. Load: 200 kg (441 lbs) or less (continuous)
Max. Vert. Intermittent Load: 800 kg (1764 lbs) (momentary)
Backlash: AZ: 1 degree EL: 1 degree
Wind Loading Area: 0.75 m2 x 0.6 m or less. (Pole Type)
Mast Size: φ38 to φ63
360 degree Rotation Time: 40~100 sec
180 degree Elevation Time: N/A
Boom Diameter: N/A
Rotator Diameter x Height: 186 x 300
Weight: 3.6 kg
Cable Requirement: 6
Rotator Dimensions: φ186 x 300 mm (φ7.3 x 11.8 inch)
Braking Type: Mechanical and Electrical stoppers
