Sirio Tornado 50-60 Base Vertical Antenna

$250.00

Description

Tornado 50-60: This Sirio Tornado 50-60 is an HF basic antenna with a length of 4.10 meters and a maximum power of 1000 Watt (CW). Sirio Tornado 50-60 Omni Directional 6M band (50 – 60MHz) base antenna, is tunable by whip length adjustment. A very popular high quality 6m band base antenna.

Features:
Base station antenna, Mono-band
Low-gain, Omnidirectional
Tunable by whip length adjust
Made of aluminum alloy 6063 T-832

Specifications:
Type: 5/8 λ Ground plane
Frequency Range: 50…60 MHz
Gain: 1.2 dBd – 3.35 dBi
Bandwidth @ SWR ≤2: ≥3.1 MHz @ 50 MHz
Max. Power (CW) @ 30°C: 1000 Watts
Connector: UHF-female

Mechanical Data:
Materials: Aluminium, Brass, Nylon
Height (approx.): 4100mm
Radial length: 1170mm
Weight (approx.): 2250g
Mounting mast: Ø 35-42 mm
Wind resistance: 150 Km/h
Wind surface: 0.12 m2

Note: Use a good coax cable like RG-8 or RG-213 as short as possible to get the best performance and we recommend to mount your antenna as far as possible from metal roofs, walls, power lines and other antennas.
