Description
TV-41J: The Nagara TV-41J is a compact, lightweight HF V-dipole antenna carefully designed for use on 7, 14, 21 and 28 MHz. It can be installed as a 90 degree V-dipole. The maximum input power is 300 watts on SSB.
The Nagara TV-41J is a good alternative for the popular Comet H-422 that is unfortunately out of production. Main difference between these two antennas is the power handling, but for most 300 Watts SSB will be enough.
Nagara antennas are manufactured entirely in Japan and are widely recognized in the Japanese market for their high quality.
Specifications:
Frequencies: HF: 7 / 14 / 21 / 28/29 Mhz.
Bands: 10, 15, 20, 40 meter band
Gain: 7 MHz: 1.3 dBi / 14 MHz: 1.65 dBi / 21 MHz: 1.95 dBi / 28 MHz: 2.15 dBi
SSB power: 300 watts
Connector: Female PL
Impedance: 50 Ohms
1/2 wave format
Materials: High Spread Aluminum, Stainless Steel, Nylon
Mast mount: 38 to 60 mm
Assemble: Horizontal / 120° / 90°
Horizontal max. length: 10.63 m
120° max. length: 9.32 m
90° max. length: 7.64 m
Weight 5.4kg
Maximum wind load: 35m/sec
Maximum wind speed: 108 Kmph
VSWR Lower than: 1:1.5 on center frequency
