Diamond CP6S HF 6-Band Base Vertical Antenna



CP6S: The CP6S multi-band trap-vertical antenna for HF bands, covering the 80-40-20-15-10 and 6m amateur bands. Made from heavy duty aluminum, assembles easily, and yields excellent performance and reliability from a compact base station antenna. Its compact size allows for many mounting options. Minimum 15′ diameter required for mounting radials. No additional ground radials required.

Compact size
Heavy-duty aluminum antenna sections
Easy assembly
No additional ground radials required
Mounting hardware included
Radial elements can be set for one direction.

Bands covered: 3.5/7/14/21/28/29/50MHz
Element Phasing : 1/4 wave trap vertical ground plane.
Radials: Six. Trap Design.
Grounding: Direct grounding. Antenna element and radials connected to mounting pipe.
Wind resistance: 40m / sec.
Mast diameter: 30 to 62 mm
Power rated: 200W PEP
Impedance (output): 50 ohms
SWR: less than 1.5: 1
Length: 4.6m Radial length: 1.8m
Weight: 9.9 lbs (4.9kg)
Connector: SO-239 Female UHF
