Diamond A430S10R2 (2x) Yagi Directive 10-Element



A430S10R2 (x2): Diamond antenna A430S10R2 base station Yagi beam antennas feature great performance from a lightweight, easy-to-install, 10-element design. These high-gain 70cm Yagi antennas are great for base or portable use and, with their factory adjustment, eliminate the need for tuning. Includes 2 x antennas plus 1 x SS770R (144MHz/2m)(430MHz/70cm) Stack transformer.
High Gain
Easy Assembly
Great for base or portable use.
Quality Construction
Factory adjusted – no tuning required.

Model: A430S10R2(×2)
Frequency: 430 – 440MHz
Power Rating: 100 watts
Band: 430 Yagi (10 element)
Connector: UHF SO-239
Gain: 15.1dBi
Weight: 2.1kg
Beam Antenna Boom Wavelength: 1.7
Dimensions: 1190 mm x 370 mm x 830 mm
Turning radius: Appro x 835 mm
VSWR: Less than 1.5:1
Wind surface area: 0.14m2
Length: 1190 mm
FB Ratio: More than 15dB
