Diamond A144S5R2 Base 5-Element Beam



A144S5R2: The Diamond Yagi antennas represent great value. These high-gain 2M Yagi antennas are great for base or portable use and, with their factory adjustment, eliminate the need for tuning.

Features / Specifications:
High gain
Easy assembly
Great for base or portable use.
Quality construction
Yagi 5-Element beam directional antenna
Factory adjusted: No tuning required.
Power rating: 50W FM (100W pep)
Frequency: 144-148 MHz
Band: 2m Yagi (5 element)
Connector: PL-259
Gain: 9 dBi
Weight: 1.4 lbs.
Boom length: 37.5″
Max Wind resistance: 80mph
Dimensions: 950 x 1090 x 73mm
