Description
NOTE: CUSTOMER TO PAY FOR POSTAGE
BM-7920: The BM-7920 is a high quality BNC male solder pin, clamp-style coaxial connector for MIL-SPEC RG58A/U stranded core, solid PE dielectric coaxial cable (SKU: 7803-100-7803-300) and MIL-SPEC RG58 low loss, solid core, foam PE dielectric coaxial cable.
Specifications:
Frequency: DC-4 GHZ
Impedance:50 Ohms – nominal
Polarization: Straight – clamp-style
Construction: Nickel plated body and clamp nut, gold plated centre pin, PTFE insulator and neoprene O-ring
Connector: BNC male / BNC-M
Weight: – KG 0.025
