Description
827: The Sirio 827 base antenna is one of the most respected antennas around. High performance comes as standard and the 827 will let you transmit much much further than most conventional antennas, the build quality is superb, will give many years of service, and ideal also for amateur use on the very popular 10m (28Mhz) band too.
Features:
CB Base 10m band station antenna, Omnidirectional
Factory tuned at mid-band
High power handling capability
Low radiation angle for excellent DX
Equipped whit excellent multi element ground plane
Made of aluminum alloy 6063 T-832
Protection from static discharges DC-Ground
Optional radials reinforcement, anti-noise NYLON RING (P/N 2511001.00)
Radiator screws: Improved with anti corrosion treatment
Specifications:
Type: 5/8 λ ground plane
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range: 26.4 … 28.4MHz Tunable
Systems: 10m-HAM
Gain: 1.5 dBd, 3.65 dBi
Bandwidth: ≥ 2MHz @ SWR ≤ 2
Max Power: 1000 Watts (CW) continuous 3000 Watts (CW) short time
Grounding protection: DC-Ground
Connector: UHF-female (SO-239)
Mechanical Data:
Materials: Aluminium, Copper, Galvanized steel, Nylon
Height (approx): 6700 mm / 21.98 ft
Weight (approx): 6000 gr / 13.23 lb
Mounting type: On-Mast
Wind load / resistance: 264 N at 150 Km/h / 130 Km/h
Radial length (approx.): 1400 mm
ACCESSORIES:
ARO827: Anti-vibration and noise nylon ring for SIRIO 827 and Blizzard 2700 antenna.
We have heard good feedback from customers who have bought this antenna, and with a suitable antenna tuner, it seems that the 827 will load on many more bands than stated, so it becomes a very useful multiband vertical on HF.
