Description
GP-9M: This is the highest gain VHF/UHF base/repeater antenna made by Comet. Although hundreds are in use in repeater systems, it was not designed for mountain-top installation where extremely high winds, ice and other extreme conditions exist. It performs best in low to mid elevation installations where the high gain radiation pattern is most effective. These superior-quality base station antennas feature a three-piece, heavy duty, UV-stabilized fiberglass radome for many years of reliable service.
Specifications:
Coverage: 2M/70 cm
Gain & Wave: 8.5 dBi, 146 MHz, 5⁄8 Wave x 3
Gain & Wave: 11.9 dBi, 446 MHz, 5⁄8 Wave x 8
Construction: Heavy Duty Fiberglass (3 Sections)
Connector: SO-239
VSWR: 1.5:1 or less
Max Power: 200 Watts
Length: 16-Foot 9-Inches (515 cm.)
Max wind survival: 92 MPH
Weight: 5-Pounds 11 Ounces
Mounting to Mast Size: 1 1⁄4 – 2 1⁄2″ (30 / 62mm)
